Product Summary
The IC41C16100S-50KS is a 16-bit high-performance CMOS Dynamic Random Access Memory. These devices offer an accelerated cycle access called EDO Page Mode. EDO Page Mode allows 1,024 random accesses within a single row with access cycle time as short as 20 ns per 16-bit word. The Byte Write control, of upper and lower byte, makes the IC41C16100S-50K ideal for use in 16-, 32-bit wide data bus systems. These features make the IC41C16100S-50K ideally suited for high-bandwidth graphics, digital signal processing, high-performance computing systems, and peripheral applications. The IC41C16100S-50K is packaged in a 42-pin 400mil SOJ and 400mil 50- (44-) pin TSOP-2.
Parametrics
IC41C16100S-50K absolute maximum ratings: (1)VT Voltage on Any Pin Relative to GND 5V: –1.0 to +7.0 V; (2)VCC Supply Voltage 5V: –1.0 to +7.0 V; (3)IOUT Output Current: 50 mA; (4)PD Power Dissipation: 1 W; (5)TA Commercial Operation Temperature: 0 to +70 ℃; (6)Industrial Operationg Temperature: –40 to +85 ℃; (7)TSTG Storage Temperature: –55 to +125 ℃.
Features
IC41C16100S-50K features: (1)Extended Data-Out (EDO)Page Mode access cycle; (2)TTL compatible inputs and outputs; tristate I/O; (3)JEDEC standard pinout; (4)Single power supply: 5V ± 10% (IC41C16100S), 3.3V ± 10% (IC41LV16100S); (5)Byte Write and Byte Read operation via two CAS; (6)Industrail Temperature Range -40℃ to 85℃.
Diagrams
 |
